Caudalímetro radar PWF-R600/PWF-R600-R

Características

• Output multi measurement data: velocity, water level and flow rate
• Applicable to a variety of sections such as trapezoidal, circular, U-shaped, etc.
• Built-in low-power Bluetooth, can directly debug and set parameters on-site through the mobile phone APP without computer connection
• IP68 protection level, effectively prevent internal components from getting wet
• Low power consumption, support solar power.
• Historical data locally download: Use the mobile phone APP to download historical data of any period

Ventajas

• Convenient configuration software, can easily configure the parameters according to actual needs to adapt to different usage conditions
• Non-contact measurement, combined with section parameters to calculate flow, not affected by wind, temperature, haze, silt, floating objects, rain etc.
• Expandable array multi-point flow measurement, equipped with a set of flow meter and multiple sets of velocity meters, through the internal algorithm fitting, to achieve wide section flow measurement.
• With rain-proof mode, avoid the interference from rainy day
• Lightning protection circuit can protect against 6KV lightning. Effectively protect the equipment from lightning strikes on rainy days.
• Compact size, high reliability, simple&convenient for operation, setting and maintenance

Non contact radar water flow meter adopts advanced millimeter wave planar radar antenna to measure the flow velocity and water level of water bodies. And calculate the flow of the section according to the built-in hydraulic model and algorithm. The measurement process is not affected by ambient temperature, water vapor pressure on the water surface, air dust, silt, floating objects and sediments; the mobile phone APP is connected wirelessly via Bluetooth, which is convenient for on-site debugging, setting and maintenance. It is an ideal radar flow meter for open channel.
