Dissolved Oxygen Sensor
Dissolved oxygen (DO) comes from two main sources: the atmosphere and photosynthesis. Most aquatic organisms require DO to survive and it is important for chemical processes in aquatic environments.
Dissolved oxygen probes work by measuring the amount of oxygen that diffuses across a permeable (or semi-permeable) membrane into a probe (sensor). Once oxygen is inside the sensor, a chemical reduction reaction occurs, producing an electrical signal. This signal is read by the DO probe and is displayed on a meter. Pokcenser provide two categories of dissolved oxygen sensors: optical and polarographic. DO sensor for fish farming is so important.
Sales contact
Pokcenser Automation Technology Co., Ltd
Mobile: +86 181 7515 5326
Email: info@pokcenser.com
Tel: +86-731-8229 9492
PT6000 Online Turbidity Meter
Features
- Full-color screen, multi-line display
- Data logging/trend chart display
- Resolution 0.001NTU
- Multiple automatic calibration functions
- Three sets of relay control switches
- High limit, low limit, hysteresis control
Applications
- General application
- Drinking water
- Environmental sewage
- River and lake water quality
- Food, tap water
- Electroplating
- Paper making
Advantages
- 4-20mA/RS485 multiple connection methods
- Password protection to prevent non-staff from misoperation
- Panel installation and wall installation both
Turbidity sensor for process control is very important, this digital turbidity meter with probe is an industrial turbidity sensor with display, the measuring minimum value is 0.5NTU. IP65 protection level makes it ideal for industrial environment.
Resources
Technical Parameters
Model | PT6000 |
Temperature | -10~150 ℃(According to electrode) |
Temperature Resolution | 0.1℃ |
Temperature Error | ±0.3℃ |
Temperature Compensation Range | Temperature Compensation Range 0~150℃ |
Temperature Compensation | Automatically or manually |
Current Output | 2 channels of 4~20mA, 20~4mA, 0~20mA |
Communication Output | RS485 Modbus RTU |
Other Function | Data logging/Trend charting |
Relay Control Contact | Three groups: 5A 240VAC; 5A 28VDC or 120VAC |
Optional Power Supply | 85~265VAC; 9~36VDC. Power: ≤3W |
Working Environment | No strong magnetic field interference around except the earth's magnetic field |
Ambient Temperature | -10~60℃ |
Relative Humidity | ≤90% |
Protection Level | IP65 |
Instrument Weight | 0.8kg |
Instrument Dimensions | 144 × 144 × 118mm |
Installation Opening Dimensions | 137 × 137mm |
Instrument Installation Method | Panel mounted, wall mounted |
